Electrical Insulation Board Epoxy Fiberglass Mat Laminate Sheet For Insulation

Model Number : 3240/3250

Place of Origin : China

MOQ : 1000kgs

Price : basing on size and quantity

Payment Terms : T/T

Supply Ability : 200000kgs per month

Delivery Time : 30 working days

Packaging Details : pallet

Material : E-glass fiber cloth + epoxy resin

Insulation Class : B/H

Tensile strength(MD) : ≥300MPa

Vertical electric strength : ≥14.2kV/mm

Relative Permittivity (50Hz) : ≤ 5.5

Parallel breakdown voltage : ≥35kV

Dielectric dissipation (50Hz) : ≤ 0.04

Insulation Resistance (after 24h Immersion In Water) : ≥ 5.0 × 10⁴ MΩ
